Siemens SIMATIC IPC427E - Setting up the Partitions under Windows 7 Ultimate and Windows 10

Device maintenance and repair
7.4 Installing the software
SIMATIC IPC427E
90 Operating Instructions, 09/2017, A5E37454814-AB
7.4.2.2
Setting up the partitions under Windows 7 Ultimate and Windows 10
You will need to reconfigure the partitions after installing a new drive, to repair corrupt
partitions or to change the partitioning.
Partitioning of the HDD or SSD
In the factory state, the following partitions are set up on the HDD or SSD for the
Windows 7 x64 UEFI operating system:
Partition
Name
Partition size
File system
SSD: > 60 GB
SSD/HDD: > 100 GB
Primary Boot 260 MB FAT32
Second
MSR
128 MB
None
Third
System
60 GB
100 GB
NTFS, not compressed
Fourth
Data
Remainder
NTFS, not compressed
In the factory state, the following partitions are set up on the HDD or SSD for the
Windows 10 UEFI operating system:
Partition
Name
Partition size
File system
SSD: > 60 GB
SSD/HDD: > 100 GB
First
Boot
260 MB
FAT32
Second
MSR
128 MB
None
Third
System
60 GB
100 GB
NTFS, not compressed
Fourth
WinRE
500 MB
NTFS, not compressed
Fifth
Data
Remainder
NTFS, not compressed
