Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC427E
44 Operating Instructions, 09/2017, A5E37454814-AB
3.3.9
Securing the lines
Secure each line connected to the device to the strain relief using a cable tie. The cable ties
required are not included.
Requirement
● Up to 6 cable ties for USB, Ethernet
Cable tie width 3 mm max.
● 1 cutting tool
Procedure
1.
Pass the cable tie around the strain relief
bar and secure the cables as shown.
2.
Cut off the protruding ends of the cable
ties.
