Siemens SIMATIC IPC477E User Manual

Technical information
8.4 Technical specifications
SIMATIC IPC477E
Operating Instructions, 12/2016, A5E37455003-AB
135
8.4.2
Power requirements of the components
Maximum power consumption of the auxiliary components
Auxiliary components
Maximum permitted power con-
sumption
Max. total power
+5 V
+3.3 V
+12 V
USB device High current 1 A - - 10 W (for all USB devices)
Display port
-
500 mA
-
PCIe module
-
1.5 A
0.5 A
8 W (for the whole device)
1
The total power of the PCIe and USB cards may not exceed 15 W
Note
Device can overheat!
To avoid overheating, the power loss per PCIe slot should not exceed 8
watts.
8.4.3
Integrated DC power supply
Input voltage
24 V DC (-20%/+20%)
Output power of the power supply
Max. 80 W
Power failure buffering
Hold-up time ≥20 ms with 20.4 V (DC_FAIL is active after > 5 ms)
Efficiency
>85 %
Note
Inrush current
At least 5 A inrush current for 15
ms is required for device startup.
The peak value of the starting current depends on
the input voltage and the impedance of
the 24
V DC power supply. Peak currents greater than 6.5 A are possible. This will not have
a negative impact on device functionality.
