Siemens SIMATIC IPC477E User Manual

Mounting and connecting the device
3.1 Preparing for mounting
SIMATIC IPC477E
32 Operating Instructions, 12/2016, A5E37455003-AB
Mounting cutout of touch devices
Mounting cutout
Device
15"
3
19"
2 3
22"
2 3
Width w
1
396 mm
465 mm
542 mm
Height h
1
291 mm
319 mm
362 mm
1
Width and height must be interchanged for mounting in vertical format.
2
Device with capacitive multi-touch screen
3
Device with resistive single touch screen
Installation depth
Information on the overall depth is available in the section "Dimension drawings (Page 117)".
