Maintaining and servicing your device
7.4 Installing and removing hardware
SIMATIC IPC477E
92 Operating Instructions, 12/2016, A5E37455003-AB
Remove the marked battery connector.
Grip the marked battery and pull it up and
out of its holder.
For installation, follow the removal steps in reverse order and close the device.
General safety instructions (Page 19)
Repair information (Page 87)
