Maintaining and servicing your device
7.4 Installing and removing hardware
SIMATIC IPC477E
94 Operating Instructions, 12/2016, A5E37455003-AB
Note
Screws in various lengths
This procedure involves screws of various lengths:
Screws to fasten the SSD to the hard disk holder (short screws)
Screws to fasten the hard disk holder to the device (long screws)
Make sure you use the correct screws for each ope
ration.
For installation, follow the removal steps in reverse order and close the device.
Repair information (Page 87)
