Overview
1.1 Product description
SIMATIC IPC547E
Operating Instructions, 02/2014, A5E32317120-AB
11
Features
Note
Please take note of the version ordered
Depending on the configuration ordered the features and illustrations described in this
manual may differ from the features of your device.
Basic data
SIMATIC IPC547E
SIMATIC IPC547E with short enclosure
Design
• 19" rack, 4 HU
• Robust full metal case, lacquered outside
(optional) and coated inside
• Prepared for mounting telescopic rails
• Can be installed in a horizontal and vertical
position
• Tower setup with tower kit
• Lockable front door as access protection
• 19" rack, 4 HU
• Robust full metal case, coated inside and
outside
• Prepared for mounting telescopic rails
• Can be installed in a horizontal position
Enclosure
• Dust protection by means of overpressure ventilation using bearing seated front fan through
filter
• Card retainers secure PC modules for transport (vibration, shock)
Expansion card slots
• 4 × PCI
• 1 × PCIe x16 (4 lanes)
• 1 × PCIe x8 (1 lane)
• 1 × PCIe x16
You can use expansion cards with a length of
up to 312 mm.
• 4 × PCI
• 1 × PCIe x16 (2 lanes)
• 1 × PCIe x8 (1 lane)
• 1 × PCIe x16
You can use expansion cards with a length of
up to 260 mm.
Drive bays
• On the front:
– 3 × 5.25" or
– 1 × 5.25" and maximum 3 × slimline removable drive bay or
– 4 × slimline removable drive bay
and
– 1 x slimline format for DVD burner
• Internal:
– 2 x 3.5"
Power supply
100V to 240V AC
Power supply,
redundant
2 × 100V to 240V AC -
Interfaces
See chapter "Interfaces and connections (Page 16)".
