Siemens SIMATIC IPC547E User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC547E
114 Operating Instructions, 02/2014, A5E32317120-AB
8.4
Technical specifications
8.4.1
General technical specifications
Note
Applicability of technical specifications
The following
technical specifications only apply under the following conditions:
•
The device is in good working order.
•
The fan cover and filter pad are installed.
•
The device is closed.
SIMATIC IPC547E:
SIMATIC IPC547E with short enclosure:
Order numbers
6AG4104-3....-.... (for details, refer to the ordering documentation)
Dimensions
433.5 x 176.5 x 445.5 (W× H × D in mm)
433.5 x 176.5 x 355.5 (W × H × D in mm)
Detailed information on the dimensions can be found in the chapter "Dimension
drawing of the device (Page 111)".
Weight
15 up to 23 kg; depending on the equipment
Supply voltage (V
N
)
• Power supply:
100V to 240V AC
(–15 %; +10 %)
• Redundant power supply:
2 × 100V AC up to 240V AC
(–15 %; +10 %)
• Power supply:
100V to 240V AC
(–15 %; +10 %)
Input current
• Continuous current at 100 V: ≤ 6 A
• Continuous current at 240 V: ≤ 3 A
• Power supply:
At startup ≤ 80 A for 3.6 ms
• Redundant power supply:
At startup ≤ 210 A for 1.65 ms for
each module
• Power supply:
At startup ≤ 80 A for 3.6 ms
Frequency 50 to 60 Hz
Minimum 47 Hz up to 63 Hz; sinusoidal
Transient voltage interruption
20 ms at 93 V; ≤ 10 events/h; recovery time ≥ 1 s
Power consumption, at maximum
configuration
With 230 W secondary:
• Power supply:
≤ 290 W; with 80% efficiency
• Redundant power supply:
≤ 290 W; with 80% efficiency
With 230 W secondary:
• Power supply:
≤ 290 W; with 80% efficiency
Power loss, heat emission
290 W = 290 J/s = 0.28 BTU/s
