Siemens SIMATIC IPC547E User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC547E
Operating Instructions, 02/2014, A5E32317120-AB
115
SIMATIC IPC547E:
SIMATIC IPC547E with short enclosure:
Current delivery (DC) +5 V; 26 A / +3.3 V; 24 A / a total of 190 W is allowed
+12 V; 15 A / +12 V; 15 A
–12 V; 0.2 A / +5 V
aux
; 2 A
The total sum of all voltages is max. 230 W.
Noise emission < 45 dB (A) to DIN 45635
At 20 °C and in Windows idle mode the result is 40 dB (A).
Degree of protection
• IP 30 with closed front door
• IP 20 on the rear according to EN 60529
Dust protection With closed front door
Filter class G2 EN 779; particles > 0.5 mm are 99% retained
Safety
Protection class
Protection class I compliant with IEC 61140
Safety regulations
• IEC 60950-1
• EN 60950-1
• UL 60950-1
• CSA C22.2 No 60950-1-07
Electromagnetic compatibility
Emitted interference (AC) EN 61000-6-3; EN 61000-6-4;
CISPR 22, EN 55022 Class B; FCC Class A /
EN 61000-3-2 class D, EN 61000-3-3
Noise immunity:
interference conducted on the
power supply lines
± 2 kV; according to IEC 61000-4-4; burst
± 1 kV; according to IEC 61000-4-5; surge symm
± 2 kV; according to IEC 61000-4-5; surge symm
Noise immunity on signal lines ± 2 kV; according to IEC 61000-4-4; burst; length > 30 m
± 1 kV; according to IEC 61000-4-4; burst; length < 30 m
± 2 kV; according to IEC 61000-4-5; burst; length > 30 m
Immunity to discharges of static
electricity
± 4 kV contact discharge (according to IEC 61000-4-2)
± 8 kV air discharge; (according to IEC 61000-4-2)
Immunity to RF interference
• 10 V/m; 80 up to 1000 MHz
80% AM to IEC 61000-4-3
• 3 V/m; 1.4 to 2 GHz
80% AM to IEC 61000-4-3
• 1 V/m; 2 up to 2.7 GHz
80% AM to IEC 61000-4-3
• 10 V; 150 kHz up to 80 MHz
80% AM to IEC 61000-4-6
Magnetic field
30 A/m; 50 Hz; 60 Hz (according to IEC 61000-4-8)
