Siemens SIMATIC IPC547E User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC547E
116 Operating Instructions, 02/2014, A5E32317120-AB
Ambient conditions
Climatic ambient conditions
Temperature
Tested according to IEC 60068-2-2; IEC 60068-2-1; IEC 60068-2-14
Operation +5 °C up to +40 °C
1
Gradient: ≤ 10 K/h; no condensation
Storage/transportation –20 °C up to +60 °C
Gradient: ≤ 20 K/h; no condensation
Relative humidity
Tested according to IEC 60068-2-78; IEC 60068-2-30
Operation 5 % up to 80% at 25 °C; no condensation
Gradient: ≤ 10 K/h; no condensation
Storage/transportation 5 % up to 95% at 25 °C; no condensation
Gradient: ≤ 20 K/h; no condensation
Atmospheric pressure
Operation 1080 up to 795 hPa,
Corresponds to an altitude of -1000 m to 2000 m
Storage/transportation 1080 up to 660 hPa,
Corresponds to an altitude of -1000 m to 3500 m
Mechanical ambient conditions
Vibration
• Operation
2
• Storage/transportation
Tested according to IEC 60068-2-6; 10 cycles
• 20 up to 58 Hz; amplitude 0.015 mm; 58 up to 200 Hz: 2 m/s
2
• 5 up to 8.51 Hz; amplitude 3.5 mm; 8.51 up to 500 Hz: 9.8 m/s
2
Resistance to shock
• Operation
2
• Storage/transportation
Tested in accordance with IEC 60068-2-27
• Half-sine; 9.8 m/s
2
; 20 ms; 100 shocks per axis
• Half-sine; 250 m/s
2
; 6 ms; 1000 shocks per axis
Special features
Quality assurance
In accordance with ISO 9001
1
No burner operation.
At +5 °C up to +35 °C, without limitation; CPU up to 65 W power loss; see notes on retrofitting
2
The device must be free of any mechanical faults when installing hard drives in removable
drive bays. No
mechanical interferences may be present during the burning process when using DVD burner drives.
