Installing and connecting the device
3.2 Mounting the device
SIMATIC IPC547E
34 Operating Instructions, 02/2014, A5E32317120-AB
Microsoft Windows Product Key COA label
Ethernet address 1, MAC address
BIOS setup > "Main"
menu
or:
Ethernet address 2, MAC address
(not for SIMATIC IPC547E with short
1. Copy the order number, serial number and manufacturing version in the table listed
above.
2. Copy the Windows "Product Key" to the table.
3. Copy the Ethernet addresses from the component label to the table.
The Ethernet addresses can also be found in the BIOS setup (F2 key) under "Main >
System Information", entries "LAN 1 MAC" and "LAN 2 MAC".
Mounting the device
3.2.1
A high voltage may be present in the switchgear cabinet and could cause a dangerous
electric shock.
It may result in death or serious physical injury.
Isolate the power supply to the switchgear cabinet before opening it. Ensure that the power
to the switchgear cabinet cannot be turned on accidentally.
