Siemens SIMATIC IPC547E User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC547E
Operating Instructions, 02/2014, A5E32317120-AB
117
Motherboard
SIMATIC IPC547E:
SIMATIC IPC547E with short enclosure:
Chipset
Intel
®
LynxPoint 8 series (Q87)
Intel
®
LynxPoint 8 series (H81)
Processor
• Intel
®
Pentium
®
Dual Core™ G3420
(2C/2T; 3.2 GHz; 3 MB cache)
• Intel
®
Core™ i5-4570S
(4C/4T; 2.9 (3.6) GHz; 6 MB cache;
iAMT)
• Intel
®
Core™ i7-4770S
(4C/8T; 3.1 (3.9) GHz; 8 MB cache;
iAMT)
• Intel® Celeron® G1820
(2C/2T; 2.7 GHz; 2 MB cache)
• Intel
®
Pentium
®
Dual Core™ G3420
(2C/2T; 3.2 GHz; 3 MB cache)
RAID (on-board) Intel
®
PCH with Intel
®
Rapid Storage
Technology
-
Slots for memory modules 4 x DIMM slots for DDR3, expandable to
32 GB
2 x DIMM slots for DDR3, expandable to
16 GB
Main memory 2 up to 32 GB; DDR3 1600 SDRAM
(PC3-12800)
2 up to 16 GB; DDR3 1600 SDRAM
(PC3-12800)
Max. of 3.2 GB can be used for 32-bit versions of operating system and applications;
see order documents for equipment
Expansion card slots
• 4 × PCI
• 1 × PCIe x16 (4 lanes); Gen 2.0
• 1 × PCIe x8 (1 lane); Gen 2.0
• 1 × PCIe x16; Gen 3.0
You can use expansion cards with a
length of up to 312 mm.
• 4 × PCI
• 1 × PCIe x16 (2 lanes); Gen 2.0
• 1 × PCIe x8 (1 lane); Gen 2.0
• 1 × PCIe x16; Gen 2.0
You can use expansion cards with a
length of up to 260 mm.
Power consumption
per PCI slot,
maximum permitted
• 5 V; 5 A or 3.3 V; 7 A
• 12 V; 0.5 A
• 12 V; 0.05 A
• 3.3 V
aux
; 0.4 A
Power consumption
per PCIe slot with
x4 expansion card,
maximum permitted
• 3.3 V; 3 A
• 12 V; 2.1 A
• 3.3 V
aux
; 0.4 A
Power consumption
per PCIe slot with
x16 expansion card,
maximum permitted
• 3.3 V; 3 A
• 12 V; 2.1 A
• 3.3 V
aux
; 0.4 A
Power consumption per slot,
permitted
≤ 25 W
Power loss all slots,
permitted
≤ 80 W
In sum, the current for 3.3 V
aux
may not exceed 1.2 A.
