Siemens SIMATIC IPC547E User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC547E
Operating Instructions, 02/2014, A5E32317120-AB
119
Graphics
SIMATIC IPC547E:
SIMATIC IPC547E with short enclosure:
Graphic controller
• Intel
®
HD Graphics 4400
(integrated in processor:
Intel
®
Pentium® Dual Core™ G3420)
• Intel
®
HD Graphics 4600
(integrated in processor:
Intel
®
Core™ i5-4570S)
• Intel
®
HD Graphics 4600
(integrated in processor:
Intel
®
Core™ I7-4770S)
• Intel® HD Graphics 4400
(integrated in processor:
Intel® Celeron® G1820)
• Intel
®
HD Graphics 4400
(integrated in processor:
Intel
®
Pentium® Dual Core™ G3420)
Graphics memory Dynamic Video Memory Technology,
occupies 32 MB to 1.7 GB of main memory
Resolutions/frequencies/colors
• DVI (VGA via adapter) up to 1920 x 1200 pixels at 60 Hz, color depth up to
32-bit/pixel
• DisplayPort up to 3840 x 2160 pixels at 60 Hz; color depth up to 32-bit/pixel
Graphics card (optional) PCIe x16; Dual Head; 2 × DisplayPort; 2 × VGA or 2 × DVI-D
1
• Type: NVIDIA NVS 300, 512 MB of graphics memory
• Maximum resolution:
– DisplayPort 2560 × 1600 at 60 Hz; 32-bit color depth
– DVI 1920 × 1200 at 60 Hz; 32-bit color depth
– VGA 2048 × 1536 at 60 Hz; 32-bit color depth
1
Adapter for VGA and DVI-D supplied
Interfaces
SIMATIC IPC547E:
SIMATIC IPC547E with short enclosure:
COM 1, Serial interface 1 (V.24), 9-pole sub D
socket
-
COM 2 (optional) Serial interface 2 (V.24), 9-pole sub D socket
LPT (optional) Parallel interface (standard, EPP and ECP mode)
Port for printer with parallel interface
VGA Connecting an analog monitor; via adapter cable; optional
DisplayPort V1.2
For connecting a digital monitor
DVI-I
For connecting a digital monitor
2 × DVI-D/VGA with dual-head
graphics card (optional)
For connecting two digital or analog monitors
PS/2 keyboard
Keyboard connection
PS/2 mouse
Mouse connection
