Overview
1.4 Operator controls
SIMATIC IPC547E
Operating Instructions, 02/2014, A5E32317120-AB
19
On/Off switch and alarm reset button
The following figures show the location of the on/off switch on the rear of the device for
devices with simple or redundant power supply.
The alarm reset button is only available for devices with redundant power supply.
Alarm reset button can be used to switch off the warning signal
The On/off button is located on the front of the device behind the front door and is used to
start and shut down the operating system.
You can find additional information in the chapters "Switching on the device (Page 47)" and
"Switching off the device (Page 53)."
