Expanding and assigning parameters to the device
6.3 Open the device
SIMATIC IPC547E
Operating Instructions, 02/2014, A5E32317120-AB
63
Limitation of liability
All technical specifications and approvals apply only to expansions which are approved by
the Siemens AG. We are not liable for functional limitations caused by the use of third-party
devices or components.
Observe the installation instructions for the components. UL approval of the device is valid
only if UL-approved components are used in observance of their intended purpose
("Conditions of Acceptability").
Requirement
● The device is fully disconnected from the mains voltage, see chapter "Switching off the
device (Page 53)".
● All connection cables are unplugged.
● T10 screwdriver
Procedure
1.
Remove the highlighted retaining
screws.
2.
Lift the enclosure cover from the back
and remove it.
3.
If necessary, remove the fan cover, see
chapter "Remove the fan cover
(Page 62)".
