Detailed descriptions
16.5 BIOS Setup
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
185
Advanced menu > Video Configuration
Figure 16-8 Submenu Advanced menu > Video Configuration
Entry Meaning
Primary video device Selection of the primary video interface to which the boot
messages are to be output:
IGD: Internal onboard graphics
PEG: PCIExpress graphics (internal graphics is deactivated)
PCI: PCI graphics (internal graphics is deactivated)
IGD boot type Selection of the video device that is used during booting.
VBIOS default: The graphics specified by the VIDEO BIOS is
used.
CRT: VGA screen
EFP: External Flat Panel (DVI)
CRT+EFP: VGA and DVI screen
IGD Dual View DVI/CRT Activate/deactivate the dual view mode: Simultaneous operation
of 2 monitors (CRT and DVI) by means of adapter (splitter) at
the DVI output of the device.
