Commissioning
7.4 Notes on operation
SIMATIC IPC647C
50 Operating Instructions, 12/2010, A5E02669337-02
3 41 2
Figure 7-4 Drives in the removable rack
Assigned LED
1
RAID
BIOS
RAID software SATA
interface
Installation location Enclosure
labeling
HDD1 ALARM ②
Port 0 Device Port 0 SATA0
Removable rack ③
1
HDD2 ALARM ①
Port 2 Device Port 2 SATA2
Removable rack ④
2
21 3
Figure 7-5 Drive in vibration damped drive rack ③
Assigned LED
1
RAID
BIOS
RAID software SATA
interface
Installation location Enclosure
labeling
HDD1 ALARM Port 0 Device Port 0 SATA0
Drive rack
③
Drive
①
1
HDD2 ALARM Port 2 Device Port 2 SATA2
Drive rack ③
Drive
②
2
1
If the hard disk is defective and SIMATIC monitoring software is installed, the LEDs ⑤ and
⑥ light up individually or simultaneously on the front.
