3.1 Overview of the product characteristics
Table 3- 1 Overview of the product characteristics
Device type SCALANCE
X104-2 X106-1 X108 X108PoE X112-2 X116 X124
SIMATIC environment + + + + + + +
Diagnostics LED + + + + + + +
24 V DC + + + + + + +
Compact housing
(securing collar, etc.)
+ + + + + + +
2x 24 V DC + + + + + + +
Signaling contact + on-site
operation
+ + + + + + +
Diagnostics: Web, SNMP,
PROFINET
- - - - - - -
Passive ring redundancy - - - - - - -
C-PLUG - - - - - - -
Ring redundancy with RM - - - - - - -
Standby redundancy - - - - - - -
IRT capability - - - - - - -
Fast learning - - - - - - -
Passive listening - - - - - - -
Log table - - - - - - -
SNTP + SICLOCK - - - - - - -
Cut Through - - - - - - -
Number of PoE ports - - - 2 - - -
Fast learning:
Quick recognition of MAC addresses on the device that change during operation (for
example, when an end node is reconnected).
Table 3- 2 Overview of the connection options
Device type SCALANCE
X104-2 X106-1 X108 X108PoE X112-2 X116 X124
TP (RJ-45)
Fast Ethernet 10 / 100 Mbps
4 6 8 8 12 16 24
Fiber multimode (BFOC)
Fast Ethernet 100 Mbps
2 1 - - 2 - -
