SCALANCE X-100
Operating Instructions, 04, A2B00060666D
55
Technical specifications
6
6.1 Technical specifications
Table 6- 1 Connectors
Device type
SCALANCE
Attachment of end
devices or network
components over
twisted pair
Connecting end devices
or network components
over fiber-optic
Connector for power
supply
Connector for
signaling contact
X104-2 4 x RJ-45 sockets with
MDI-X pinning
10/100 Mbps (half/ full
duplex)
2 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in
terminal block
1 x 2-pin plug-in terminal
block
X106-1 6 x RJ-45 sockets with
MDI-X pinning
10/100 Mbps (half/full
duplex)
1 x BFOC-sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in
terminal block
1 x 2-pin plug-in terminal
block
X108 8 x RJ-45 jacks with
MDI-X pinning
10/100 Mbps (half/ full
duplex)
- 1 x 4-pin plug-in
terminal block
1 x 2-pin plug-in terminal
block
X108PoE 8 x RJ-45 jacks with
MDI-X pinning
10/100 Mbps (half/ full
duplex)
- 1 x 4-pin plug-in
terminal block
1 x 2-pin plug-in terminal
block
X112-2 12 x RJ-45 jacks with
MDI-X pinning 10/100
Mbps (half/full duplex)
2 x BFOC-sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in
terminal block
1 x 2-pin plug-in terminal
block
X116 16 x RJ-45 jacks with
MDI-X pinning
10/100 Mbps (half/full
duplex)
- 1 x 4-pin plug-in
terminal block
1 x 2-pin plug-in terminal
block
X124 24 x RJ-45 jacks with
MDI-X pinning
10/100 Mbps (half/ full
duplex)
- 1 x 4-pin plug-in
terminal block
1 x 2-pin plug-in terminal
block
