Siemens SIMATIC NET SCALANCE X-100 Series

Technical specifications
6.1 Technical specifications
SCALANCE X-100
56 Operating Instructions, 04, A2B00060666D
Table 6- 2 Electrical data
Device type
SCALANCE
Power supply
2 x 24 V DC
(18-32 V DC)
Safety extra-low voltage
(SELV)
Power loss at
24 V DC
Current consumption
at rated voltage
Overcurrent protection at
input
PTC resettable fuse
(0.6 A / 60 V)
X104-2 + 3.8 W 160 mA +
X106-1 + 3.6 W 150 mA +
X108 + 3.36 W 140 mA +
X108PoE + 10.0 W 1700 mA -
X112-2 + 5.16 W 215 mA -
X116 + 4.40 W 185 mA -
X124 + 4.80 W 200 mA -
Table 6- 3 Signaling contact
Device type
SCALANCE
Voltage at signaling contact Current through signaling contact
X104-2 24 V DC max. 100 mA
X106-1 24 V DC max. 100 mA
X108 24 V DC max. 100 mA
X108PoE 24 V DC max. 100 mA
X112-2 24 V DC max. 100 mA
X116 24 V DC max. 100 mA
X124 24 V DC max. 100 mA
Table 6- 4 Permitted cable lengths (copper)
Device type
SCALANCE
0 - 55 m
IE TP torsion cable with
IE FC RJ-45 Plug 180
or
0 - 45 m IE TP torsion
cable with IE outlet RJ-
45 + 10 m TP cord
0 - 85 m
IE FC TP marine / trailing / flexible /
festoon / FRNC / festoon / food cable
with IE FC RJ-45 Plug 180
or
0 - 75 m IE FC TP marine / trailing /
flexible / festoon / FRNC / food cable
+ 10 m TP cord over IE FC outlet RJ-
45
0 - 100 m
IE FC TP standard cable with IE FC RJ-
45 plug 180
or
over IE FC outlet RJ-45 with 0 - 90 m IE
FC TP standard cable + 10 m TP cord
X104-2 + + +
X106-1 + + +
X108 + + +
X108PoE + + +
X112-2 + + +
X116 + + +
X124 + + +
