Siemens SIMATIC NET SCALANCE X-100 Series

Technical specifications
6.1 Technical specifications
SCALANCE X-100
Operating Instructions, 04, A2B00060666D
57
Table 6- 5 Permitted cable lengths (fiber-optic)
Device type
SCALANCE
1 - 50 m
980/1000
plastic optical
fiber (POF)
1 - 100 m
200/230 polymer
cladded fiber (PCF)
6 dB max. permitted FO
cable attenuation with
3 dB link power margin
0 - 3,000 m
glass FOC
62.5/125 µm or
50/125 µm glass fiber;
≤ 1 dB/km at 1300 nm;
≥ 600 MHz
x
km;
6 dB max. permitted FO
cable attenuation with 3
dB link power margin
0 - 26000 m
glass FOC
10/125 µm single mode fiber;
0.5 dB/km at 1300 nm;
13 dB max. permitted FO
cable attenuation with 2 dB
link power margin
X104-2 - - + -
X106-1 - - + -
X108 - - - -
X108PoE - - - -
X112-2 - - + -
X116 - - - -
X124 - - - -
Table 6- 6 Aging time / learnable MAC addresses / MTBF
Device type
SCALANCE
Aging time learnable MAC addresses MTBF
X104-2 30 seconds
2048 134.87 years
X106-1 30 seconds 2048 136.65 years
X108 30 seconds 2048 139.83 years
X108PoE 30 seconds 2048 61.64 years
X112-2 30 seconds 8096 61.3 years
X116 30 seconds 8096 61.3 years
X124 30 seconds 8096 49.3 years
Table 6- 7 Permitted environmental conditions / EMC
Device type
SCALANCE
Operating temperature Storage/transport
temperature
Relative
humidity in
operation
Operating altitude at max.
xx°C ambient temperature
X104-2 -10 to +60° C -40 to +80° C ‹ 95 %
(no
condensation)
2000 m at max. 56° C
3000 m at max. 50° C
X106-1 -10 to +60° C -40 to +80° C ‹ 95 %
(no
condensation)
2000 m at max. 56° C
3000 m at max. 50° C
X108 -20 to +70° C -40 to +80° C ‹ 95 %
(no
condensation)
2000 m at max. 56° C
3000 m at max. 50° C
