3.12 Displays
SCALANCE X-100
Operating Instructions, 04, A2B00060666D
39
Device type
SCALANCE
Green LED lit LED not lit
X104-2 1 2
X106-1 1 2
X108 1 2
X108PoE 1 2
X112-2 1 2
X116 1 2
X124 1 2
1. Power supply L1 or L2 is connected.
2. Power supply L1 and/or L2 not connected or <14 V.
3.12.3 Port status indicator (green/yellow LEDs)
Port status indicator (green/yellow LEDs)
The LEDs signal that the device can adopt the following statuses.
The status of the interfaces is indicated by two-color LEDs:
Device type SCALANCE
Number of port
LEDs
LED lit green LED lit yellow LED flashes yellow
X104-2 6 port LEDs 1 2 3
X106-1 7 port LEDs 1 2 3
X108 8 port LEDs 1 2 3
X108PoE 8 port LEDs 1 2 3
X112-2 14 port LEDs 1 2 3
X116 16 port LEDs 1 2 3
X124 24 port LEDs 1 2 3
1. TP link exists, no data reception.
2. TP link, data received at TP port.
3. Setting or display of the fault mask.
