Product properties
3.5 SCALANCE X106-1
SCALANCE X-100
Operating Instructions, 04, A2B00060666D
17
3.5 SCALANCE X106-1
3.5.1 SCALANCE X106-1 product characteristics
Possible connections
The SCALANCE X106-1 has six RJ-45 jacks and a BFOC port for the connection of end
devices or other network segments.
Note
The BFOC
socket (Bayonet Fiber Optic Connector) corresponds to the ST socket.
Figure 3-3 SCALANCE X106-1
