Product properties
3.7 SCALANCE X108PoE
SCALANCE X-100
24 Operating Instructions, 04, A2B00060666D
3.7 SCALANCE X108PoE
3.7.1 SCALANCE X108 PoE product characteristics
Possible connections
The SCALANCE X108 PoE has eight RJ-45 jacks for the connection of end devices or other
network segments.
Figure 3-7 SCALANCE X108PoE
3.7.2 SCALANCE X108 PoE TP ports
Connector pinout
Note
To supply Po
E end devices with power, 4- or 8-wire connecting cables (complying with IEEE
802.3) can be used.
On the SCALANCE X108 PoE, the TP ports are implemented as RJ-45 sockets with MDI-X
assignment (Medium Dependent Interface–Autocrossover) of a network component.
