Page #6 background image
Introduction
SCALANCE X-100
6 Operating Instructions, 04, A2B00060666D
Standards and approvals
The Industrial Ethernet switches of the SCALANCE X-100 product line meet the
requirements for the CE, UL, C-Tick, FM and ATEX marks. You will find detailed information
in the section "Approvals and Markings" in this commissioning manual in the "Approvals"
table.
Note
The specifie
d approvals apply only when the corresponding mark is printed on the product.
What is possible?
The devices of the SCALANCE X100 product line allow the cost-effective installation of
Industrial Ethernet bus and star structures with switching functionality. The
SCALANCE X104-2, SCALANCE X106-1 and SCALANCE X112-2 also allow the switchover
between electrical/optical media. SCALANCE X devices with the suffix PoE also allow the
supply of power to end devices over Ethernet cables with Power-over-Ethernet complying
with 802.3af.
Note
It is not possible to use devices of the S
CALANCE X-100 product line in a redundant ring
because they do not support redundancy.
Note
If devices
of the SCALANCE X-100 product line are supplied over long 24 V power supply
lines or networks, measures are necessary to prevent interference by strong electromagnetic
pulses on the supply lines. These can result, for example, as a result of lightning or large
inductive loads.
One of the tests to attest the immunity of devices of the SCALANCE X-100 product line to
electromagnetic interference was the "surge immunity test" according to EN61000-4-5. This
test requires overvoltage protection for the power supply lines. A suitable device is, for
example, the Dehn Blitzductor VT AD 24 V type no. 918 402 or comparable protective
element.
Manufacturer:
DEHN+SÖHNE GmbH+Co.KG Hans Dehn Str.1 Postfach 1640 D-92306 Neumarkt,
Germany
WARNING
When used under hazardous conditions (zone 2), a switch of the SCALANCE X-100
product line must be installed in an enclosure.
To comply with ATEX95 (EN 60079-15), this enclosure must meet the requirements of at
least IP54 in compliance with EN 60529.
WARNING – EXPLOSION HAZARD: DO NOT DISCONNECT EQUIPMENT WHEN A
FLAMMABLE OR COMBUSTIBLE ATMOSPHERE IS PRESENT.
