Synchronization modules
12.1 Synchronization modules for the CPU 410-5H
CPU 410-5H Process Automation
System Manual, 09/2014, A5E31622160-AB
205
Technical data
Technical data
6ES7 960–1AA06–0XA0
6ES7 960–1AB06–0XA0
Maximum distance between the
CPUs
10 m 10 km
Supply voltage 3.3 V, supplied by the CPU 3.3 V, supplied by the CPU
Current consumption
220 mA
240 mA
Power loss
Wavelength of the optical
transceivers
0.77 W
850 nm
0.83 W
1310 nm
Maximal permitted attenuation of the
fiber-optic cable
7.5 dB 9.5 dB
Maximum permitted difference in
cable lengths
9 m 50 m
Dimensions W x H x D (mm)
13 x 14 x 58
13 x 14 x 58
Weight
0.014 kg
0.014 kg
