Siemens SIMATIC PCS 7 CPU 410-5H User Manual

Technical data
14.1 Technical specifications of the CPU 410-5H; (6ES7 410-5HX08-0AB0)
CPU 410-5H Process Automation
System Manual, 09/2014, A5E31622160-AB
219
6ES7410-5HX08-0AB0
OB
Number, max.
See instruction list
Size, max.
64 KB
Number of free-cycle OBs
1; OB 1
Number of time-of-day interrupt OBs
8; OB 10-17
Number of time-delay interrupt OBs
4; OB 20-23
Number of cyclic interrupt OBs
9; OB 30-38 (= Process tasks)
Number of process interrupt OBs
8; OB 40-47
Number of DPV1 interrupt OBs
3; OB 55-57
Number of restart OBs
2; OB 100, 102
Number of asynchronous error OBs
9; OB 80-88
Number of synchronous error OBs
2; OB 121, 122
Nesting depth
Per priority class
24
Additionally within an error OB
2
Counters, timers and their retentivity
S7 counters
Quantity
2048
Retentivity
•
Can be set
Yes
Counting range
•
Lower limit
0
•
Upper limit
999
IEC counter
Available
Yes
Type
SFB
Quantity
Unlimited (limited only by the work memory)
S7 timers
Quantity
2048
Retentivity
•
Can be set
Yes
Time range
•
Lower limit
10 ms
•
Upper limit
9990 s
IEC timer
Available
Yes
Type
SFB
Quantity
Unlimited (limited only by the work memory)
