Technical data
14.1 Technical specifications of the CPU 410-5H; (6ES7 410-5HX08-0AB0)
CPU 410-5H Process Automation
220 System Manual, 09/2014, A5E31622160-AB
6ES7410-5HX08-0AB0
Data areas and their retentivity
Retentive data area, total
Total work and load memory (with backup battery)
Bit memory
Nu
mber, max. 16384 bytes
Retentivity, available
Yes
Number of clock memories
8; in 1 memory byte
Data blocks
Number, max.
16000; number range: 1 to 16000
Size, max.
64 KB
Local data
Can be set, max.
64 KB
Default
64 KB
Address range
I/O address range
Inputs
16 Kbyte; up to 7 500 IO
Outputs
16 Kbyte; up to 7 500 IO
of those distributed
•
DP interface, inputs
6 Kbyte; up to 2 800 IO (channels)
•
DP interface, outputs
6 Kbyte; up to 2 800 IO (channels)
•
PN interface, inputs
8 Kbyte; up to 3 800 IO (channels)
•
PN interface, outputs
8 Kbyte; up to 3 800 IO (channels)
Process image
Inputs, can be set
16 KB
Outputs, can be set
16 KB
Inputs, preset
16 KB
Outputs, preset
16 KB
Consistent data, max.
244 bytes
Access to consistent data in the process image
Yes
Process image partitions
Number of process image partitions, max.
15
Digital channels
Inputs
131072, max.
Outputs
131072, max.
Inputs, central
131072, max.
Outputs, central
131072, max.
Max. number of addressable digital I/O
131072
