Technical data
14.1 Technical specifications of the CPU 410-5H; (6ES7 410-5HX08-0AB0)
CPU 410-5H Process Automation
System Manual, 09/2014, A5E31622160-AB
225
6ES7410-5HX08-0AB0
Media redundancy
Supported
Yes
Changeover time at line interruption, typ.
200 ms
Number of nodes on the ring, max.
50
Functionality
PROFINET IO controller
Yes
PROFINET IO device
No
PROFINET CBA
No
Open IE communication
Yes
Web server
No
PROFINET IO controller
Transmission rate, max.
100 Mbps
Number of connectable IO devices, max.
250
Number of connectable IO devices for RT, max.
250
•
of which in line, max.
250
Shared device, supported
No; but can be used in S7 framework
Prioritized startup supported
No
Enabling/disabling of IO devices
No
Hot swapping of IO devices (partner ports), supported
No
Device replacement without removable medium
Yes
Send clocks
250 µs, 500 µs, 1 ms, 2 ms, 4 ms
Update time
250 µs to 512 ms, minimum value depends on the amount
of configured user data and the configured operating mode
or redundancy mode
Services
•
PG/OP communication
Yes
•
S7 routing
Yes
•
S7 communication
Yes
•
Open IE communication
Yes
Address range
•
Inputs, max.
8 Kbyte; up to 3 800 IO (channels)
•
Outputs, max.
8 Kbyte; up to 3 800 IO (channels)
•
User data consistency, max.
1024 bytes
Open IE communication
Open IE communication, supported
Yes
Number of connections, max.
118
Local port numbers used by the system
0, 20, 21, 25, 102, 135, 161, 34962, 34963, 34964, 65532,
65533, 65534, 65535
Keep Alive function supported
Yes
