Technical data
14.1 Technical specifications of the CPU 410-5H; (6ES7 410-5HX08-0AB0)
CPU 410-5H Process Automation
226 System Manual, 09/2014, A5E31622160-AB
6ES7410-5HX08-0AB0
4. Interface
Interface type
Plug-in synchronization module (FOC)
Plug
-in interface modules Synchronization module 6ES7960-1AA06-0XA0 or
6ES7960-1AB06-0XA0
5. Interface
Interface type
Plug-in synchronization module (FOC)
Plug
-in interface modules Synchronization module 6ES7960-1AA06-0XA0 or
6ES7960-1AB06-0XA0
Protocols
PROFINET IO
Yes
PROFINET CBA
No
PROFIsafe
Yes
PROFIBUS
Yes
Protocols (Ethernet)
TCP/IP
Yes
Other protocols
AS-i
Yes; via add-on
MODBUS
Yes; via add-on
Foundation Fieldbus
Yes; via DP/FF link
Communication functions
PG/OP communication
Yes
•
Number of connectable OPs without message processing
119
•
Number of connectable OPs with message processing
119; when using Alarm_S/SQ and Alarm_D/DQ
Data record routing
Yes
S7 routing
Yes
S7 communication
Supported
Yes
As server
Yes
As client
Yes
User data per job, max.
64 KB
User data per job (consistent), max.
462 bytes; 1 variable
S5-compatible communication
Supported
Yes; (via CP, max. 10 and FC AG_SEND and FC
AG_RECV)
User data per job, max.
8 KB
User data per job (consistent), max.
240 bytes
Number of simultaneous AG
-SEND/AG-RECV jobs per CPU,
max.
64/64
Standard communication (FMS)
Supported
Yes; via CP and loadable FBs
