7.5.3 Assignment of the Internal Ports on the Motherboard
Port Position Connector Description
Memory internal X3, X4, X5 3 DIMM slot, 64 bits
Processor internal X1 Socket for FCPGA mobile processor
Bus extender internal X20 Socket for bus extender, assigned with ISA
and PCI bus signals
Power supply internal X50 20 pin connector for power supply
Floppy internal X26 two drives are possible (82078 compatible)
360kB, 720kB, 1.2MB, 1.44MB
3F0h-3F7h, 370h-377h, can be disabled
IRQ 6, edge-triggered
34 pin, socket for standard floppy disk drive
primary EIDE
(e.g. hard disk)
internal X7 170h-177h, 1F0h-1F7h, can be disabled
IRQ14, IRQ15, edge-triggered
40 pin, 2.54 mm male connector
(3.5” HD, primary),
a maximum of two drives are operable
secondary EIDE
(e.g. CD-ROM)
internal X11 170h-177h, 1F0h-1F7h, can be disabled
IRQ14, IRQ15, edge-triggered
40 pin, 2.54 mm male connector ,
a maximum of two drives are operable
V.24/TTY mo-
dule
*
internal X28, X29 Connection for V.24/TTY transmitter hybrid *
(physical interface)
PS connection
for CPU fan
internal X41 Power supply for CPU fan,
3 pin, male connector
PS connection
for device fan
internal X42
X43
Power supply for device fan (controlled),
3 pin, male connector
PS connection
for drive fan
internal X40 Power supply for device fan (uncontrolled),
3pin, male connector
Connection for
SCSI LED
internal X39 Input fpr SCSI drive activity display
* Optional product feature
Port to the Bus Unit, X20
The Rack PC has a bus board with seven PCI slots, one ISA slot and two shared
ISA /PCI slots. Ten expansion cards can simultaneously be installed to ISA
specification (Rev. 3.1) and PCI specification (Rev. 2.0). All the PCI slots can be
used as masters. Only 5V PCI modules are operable.
The power supply to the expansion cards is effected via the connection of the bus
board with the motherboard and additionally directly from the power supply unit.
The connection to the motherboard is effected by a gold-plated direct connector of
the type ‘PCI, 64 bit’. All the necessary bus signals (ISA and PCI) are applied to
this connector. The following table shows the connector assignment.
