4.1.3 Components Visible after Opening the Unit
Components
Once you have removed the housing cover of your unit, the components are
visible:
1 Motherboard
2 Memory expansion
3 Processor
4 Front drive holder
5 Backup battery
6 Power supply
7 Rear drive holder
8 Bus board
2
3
4
5
6
78
1
Figure 4-2 Rack PC Open
