Technical Specifications S5-115F Manual
IEC / VDE
Safety Information
Degree of protection to IEC 529
- type IP 20
- class to IEC 536
Insulation rating
- between electrically
independent circuits
and
with circuits connected
by a central grounding
point to VDE 0160
- between all
circuits
and
central grounding point
(standard mounting rail) to VDE 0160
Test voltage sine, 50 Hz
for a rated
voltage V
e
of the
circuits (AC / DC)
V
e
= 0 to 50 V 500 V
V
e
= 50 to 125 V 1250 V
V
e
= 125 to 250 V 1500 V
Impulse voltage to IEC 255-4
for a rated
voltage V
e
of the
circuits (AC / DC)
V
e
= 0 to 50 V 1 kV, 1.2 / 50 µs
V
e
= 50 to 125 V 1 kV, 1.2 / 50 µs
V
e
= 125 to 250 V 3 kV, 1.2 / 50 µs
RI specification to VDE 0871
- limit class A
Note:
AC output modules
are not interference suppressed!
Electromagnetic Compatibility (EMC)
Noise Immunity
Damped oscillatory wave test to IEC 255-4
- AC power supply modules 2.5 kV
- DC power supply modules 1 kV
- output 24 V DC 1 kV
- input 115 V AC / 230 V AC 2.5 kV
- digital input/output modules 2.5 kV
- analog input/output modules 1 kV
- communications interfaces 1 kV
Fast transient burst test to IEC 65
(Sec) 87
- power supply modules 2 kV
- digital input/output modules 2 kV
- analog input/output modules 1 kV
- communications interfaces 1 kV
Electrostatic discharge test to IEC 801-2
(Discharge to all
parts accessible to
the operator in
normal operation)
- power supply modules 5 kV
- digital input/output modules 5 kV
- analog input/output modules 5 kV
- communications interfaces 5 kV
Radiated electromagnetic field test to IEC 801-3
- test field strength 3 V/m
Fast transient burst to IEC 801-4
- power supply modules
- digital input/output modules
- analog input/output modules
- communications interfaces
8-2 EWA 4NEB 811 6148-02
