S5-115F Manual Installation Guidelines
3.2.2 Dimension Drawings
Figure 3-15. Dimension Drawing of Mounting Racks
SIEMENS
SIMATIC S5
190.5
(7.43)
465
*
(18.14)
CR 700-2F; ER 701-1 ... 3
140
(5.46)
*
The width of the CR 700-0 (6ES5 700-0LB11) is 353 mm (13.9 in.)
EWA 4NEB 811 6148-02
3-15
