A.9 Communication interfaces
Easy Book
Manual, 03/2014, A5E02486774-AF
333
Technical specifications of the ANT794-4MR GSM/GPRS antenna
ANT794-4MR
Order number 6NH9860-1AA00
Mobile wireless networks
GSM/GPRS
Frequency ranges
• 824 to 960 MHz (GSM 850, 900)
• 1 710 to 1 880 MHz (GSM 1 800)
• 1 900 to 2 200 MHz (GSM / UMTS)
Characteristics
omnidirectional
Antenna gain
0 dB
Impedance
50 ohms
Standing wave ratio (SWR)
< 2,0
Max. power
20 W
Polarity
linear vertical
Connector
SMA
Length of antenna cable
5 m
External material
Hard PVC, UV-resistant
Degree of protection
IP20
Permitted ambient conditions
• Operating temperature
• Transport/storage temperature
• Relative humidity
• -40 °C through +70 °C
• -40 °C through +70 °C
• 100 %
External material
Hard PVC, UV-resistant
Construction Antenna with 5 m fixed cable and SMA male
connector
Dimensions (D x H) in mm
25 x 193
Weight
• Antenna incl. cable
• Fittings
• 310 g
• 54 g
Installation
With supplied bracket
Technical specifications of the flat antenna ANT794-3M
Order number
6NH9870-1AA00
Mobile wireless networks
GSM 900
GSM 1800/1900
Frequency ranges
890 - 960 MHz
1710 - 1990 MHz
Standing wave ratio (VSWR)
≤ 2:1
≤ 1,5:1
Return loss (Tx)
≈ 10 dB
≈ 14 dB
Antenna gain
0 dB
Impedance
50 ohms
