Fail-Safe Blocks
Fail-Safe Systems
A5E00085588-03
8-49
8.5.2 F_R_BO
Function
This block safely receives 10 data items of the data type F_BOOL sent from
another F-run-time group from the F_S_BO block.
The received data is stored at the outputs RD_BO_xx for further processing by
other blocks.
The input S_DB must be connected with the output of the same name of the
sending block.
The input TIMEOUT must be assigned a value for monitoring the safety-related
communication. If an updated frame is not received during this time, the system
function SFC F_CTRL is called. See "Monitoring Safety-Related Communication
Between F Run-Time Groups".
Startup Characteristics
In the first cycle after a cold or warm restart, the block outputs the substitute values
configured at the SUBBO_xx inputs. The output of the substitute values depends
on the configured execution times of the cyclic interrupts and occurs as long as the
value F_TRUE is at the output SUBS_ON, but only until the monitoring time
TIMEOUT elapses.
I/Os
Name Data Type Explanation Default
Inputs:
TIMEOUT F_TIME Monitoring time in ms for vital-
sign monitoring
T#0 ms
S_DB F_WORD Instance DB no. of the
associated F_S_BO
0
SUBBO_00 F_BOOL Substitute value for receipt
data 00
0
... ...
SUBBO_09 F_BOOL Substitute value for receipt
data 09
0
Outputs:
SUBS_ON F_BOOL Substitution values are output 0
RD_BO_00 F_BOOL Receipt data 00 0
... ...
RD_BO_09 F_BOOL Receipt data 09 0
