Fail-Safe Blocks
Fail-Safe Systems
A5E00085588-03
8-117
8.13.3 F_MUL_R
Function
This block multiplies the inputs and outputs the product at the output.
OUT = IN1 * IN2
I/Os
Name Data Type Explanation Default
Inputs:
IN1 F_REAL Multiplicand 0.0
IN2 F_REAL Multiplier 0.0
Output:
OUT F_REAL Product 0.0
Error Handling
If the operation generates an invalid REAL number the event will be recorded in
the Diagnostic Buffer.
Error Information in Diagnostic Buffer
Error Code (W#16#...) Description
75D9H
Invalid REAL number generated by the operation.
