SIMATIC VS710Quick Reference Guide
SIMATIC VS 710
A5E00032597-02
25
4.4 Installing older ProVision versions on Your
VS 710
To install or update the ProVision Runtime System (<V2.1), proceed as
indicated below. Use 1.44 Mbyte diskettes that have been loaded with the
relevant files, for example as described in ProVision Setup
(see ProVision Product Information for further details).
Switch off the VS 710
Plug the VGA monitor
into the VS 710
Type in A:\Install 1
Switch on the VS 710
Connect the host PC and
VS 710 via the RS232
interface
Watch out for system messages
(such as Change diskette)
Installation complete.
Press Ctrl-Alt-F10 key
combination to restart VS 710.
Press Ctrl-X to exit Hostkey
Type in A:\install 1 to
delete old files and load
new files from A: to C:
Insert diskette 1 in the diskette
drive of the host PC
Wait until MS-DOS prompts
with C:\
Figure 18 Installing ProVision
The VS 710 must be reset in order to restart it. The remote connection must
be disconnected on startup, either by removing the RS232 connection or by
exiting HOSTKEY. If the connection is not disconnected, ProVision does
not restart and VS 710 returns to the installation mode.
