SIMATIC VS710Quick Reference Guide
SIMATIC VS 710
A5E00032597-02
29
5.2 Digital I/O Interface
Characteristic Technical Specifications
Module-Specific Data
Number of inputs 2
Number of outputs 4
Line length, shielded 10 m
Current, Voltages, Potentials
Rated voltage
Load current supply L+
24 VDC
Permitted rated voltage
Load current supply L+
20.4 V to 28.8 V
Current consumption L+ Depends on assignment
Number of simultaneously
controllable inputs
2
Number of simultaneously
controllable outputs
4
Isolation Yes (optocoupler)
Permitted potential differences
S Between M connections
S Between input (M connection)
and central grounding point
S Isolation tested with
500 VDC
Interrupt
Interrupt Digital inputs 0 and 1 have interrupt
capability
