Siemens Simatic VS 710 User Manual

SIMATIC VS710
Quick Reference Guide
30
SIMATIC VS 710
A5E00032597-02
Characteristic Technical Specifications
Data for Selecting a Sensor
Input voltage
S Rated value
S With signal “1”
S With signal “0”
24 VDC
From 11 to 30 V
-3 V to +5 V
Input current
S With signal “1”
From 4 mA to 8 mA
Input delay time 10 µs
Data for Selecting an Actuator
Output voltage
S With signal “1”
S With signal “0”
L+-1.5 v
Max. 3 V
Output current
S With signal “1” rated value
permitted range
S With signal “0” (residual cur-
rent)
0.5 A
From 5 mA to 0.6 A
Max. 0.1 mA
Load on lamps Max. 5 W
Parallel connection of 2 outputs No
Maximum operating frequency:
S With ohmic load/lamp load
S With inductive load
500 Hz
2.0 Hz at 0.5 A
Switching delay Max. 400 µs
Limit (internal) of voltage induced
on circuit interruption
L+-39 V
Short-circuit protection at output Electronic
