SIMATIC VS710
Quick Reference Guide
4
SIMATIC VS 710
A5E00032597-02
2 VS 710 Hardware
2.1 Hardware Components
VS 710 is made up of the following hardware components:
• Metal casing (dimensions: 65x80x130, color: black) with multiple
mounting options. All ports for communication located on the back
panel of the casing.
• C-mount standard lens socket.
• High-resolution CCD chip (782x582) with square pixels, pixel
identical scanning, offset setting.
used CCD-Chip size: 6.5 mm (H) x 4.8 mm (V)
• Restart-reset, full frame shutter with an exposure range of 1/50 -
1/10000s, half-image and full-image modes.
• Parameter assignment for image formats up to 768x512.
• 100 MHz 80486 CPU (AMD) with direct image buffer access
• 16 Mbyte main memory DRAM module (SO-DIMM)
• 16 Mbyte IDE flashdisk (see Section 2.9)
• 256 Kbyte flash EPROM as BIOS memory
• 2 Mbyte image buffer
