SIMATIC VS710
Quick Reference Guide
26
SIMATIC VS 710
A5E00032597-02
5 Technical Specifications
This table contains the complete technical specifications for the VS 710.
5.1 General Specifications
Characteristic Technical Specifications
VS 710
Order Number SIMATIC VS 710: 6GF 1710-3AA
SIMATIC VS 710 (OEM): 6GF 1710-2AA
Dimensions 65 x 80 x 130 mm (W x H x D) with no mounting
bracket attached
Weight Approx. 0.750 kg (without lens)
Interfaces
to S7/M7/C7
to PC
RS485 (12 Mbps)
RS232 (115 Kbps)
Power Supply
Supply voltage (V
N
)
S Input voltage
protected
against polarity
reversal
S Voltage
interruption
(can be
jumpered)
24 VDC; (20.4 to 28.8 VDC, safety extra low voltage,
SELV). The VS 710 has no integrated protection
against high-energy surge pulses in the µs range (surge
pulse). See EMC for external measures.
Yes
≥ 20 ms
Current
consumption (I
N
)
I=480 mA (typ)/600 mA (max.)
Starting current I
1
max. 10 A; 1 ms
