Commissioning, service, troubleshooting
13.3 Service
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
277
13.3.2 Backing up and saving parameters
Always save the parameters in the memory module or in a SIMOCODE ES file. This
particularly applies if you replace a basic unit, or if you wish to transfer data from one basic
unit to another.
Saving parameters from the basic unit into the memory module
Note
This function will not be available if the TEST
/ RESET button has been disabled.
Proceed as follows:
Table 13- 15 Saving the parameters into the memory module
1. Plug the memory module into the system interface. The "Device" LED lights up yellow for
approx. 10 seconds. During this time, press the "TEST / RESET" button for approx.
3 seconds. The parameters will be saved in the memory module. After successful data
transfer, the "Device" LED flickers yellow for approx. 3 seconds.
If necessary, unplug the memory module from the system interface.
Saving parameters from the memory module into the basic unit
Note
This function will not be available if the TEST
/ RESET button has been disabled.
Proceed as follows:
Table 13- 16 Saving parameters from the memory module into the basic unit
1. Plug the memory module into the system interface. The "Device" LED lights up yellow for
approx. 10 seconds. During this time, briefly press the "TEST / RESET" button. The
parameters will be transferred to the basic unit. After successful data transfer, the "Device"
LED flashes yellow for approx. 3 seconds.
If necessary, unplug the memory module from the system interface.
Note
If the memory module is plugged in, the parameters will be transferred from the memory
module t
o the basic unit when the supply voltage is switched on.
