Mounting, wiring, connecting, system interfaces, configuration guidelines
12.3 System interfaces
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
237
Connect the system interfaces only when they are fully de-energized!
See also
Closing the system interfaces with the system interface cover (Page 247)
12.3.2 System interfaces on basic units, expansion modules, decoupling module,
current measuring modules and current / voltage measuring modules
Examples of connection of system components to the system interface and system structure
Close system interfaces not in use with the system interface cover (see Closing the system
interfaces with the system interface cover (Page 247).
System interface on the operator panels (degree of protection IP54):
To ensure degree of protection IP 54
• press the cover into the socket as far as it will go when it is used for the first time!
• When fastening the operator panel with the screws supplied, do not apply an excessive
tightening torque.
