An overview of system components
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
73
Number that can be connected to
DM-F PROFIsafe fail-safe digital module
2)
For fail-safe tripping via PROFIBUS/PROFIsafe:
2 relay enabling circuits, wired in parallel
2 relay outputs, common ground, fail-safe tripping
1 input for feedback circuit; 3 binary standard
24 V DC
110 to
240 V
3UF7330-1AB00-0
3UF7330-1AU00-0
—
—
—
—
—
—
1 (from
*E07*)
1 (from
—
—
1
1
—
—
By means of the analog module, the basic unit can
be optionally expanded by analog inputs and
outputs (0 to 20 mA).
2 inputs (passive) for inputting and 1 output for
outputting 0/4 to 20 mA signals.
The external ground-fault monitoring using
residual current transformer and ground-fault
module is normally used in the following cases:
• in cases in which power systems are grounded
with high impedance
• in cases, in which precise detection of the
ground-fault current is necessary, for example,
for condition monitoring.
— 3UF7500-1AA00-0
for connecting
a 3UL22 residual-
current transformer
— — — 1 (from
*E02*)
1 1 1
— 3UF7510-1AA00-0
for connecting
a 3UL23 residual-
— 1 1 1 (from
*E10*)
1 1
(from
*E04*)
1
Irrespective of the thermistor protection of the
basic units, an additional max. 3 analog
temperature sensors can be evaluated using a
temperature module.
Sensor types: PT100/PT1000, KTY83/KTY84 or
NTC
3 inputs for connecting up to 3 analog temperature
— 3UF7700-1AA00-0 — 1
3)
1
3)
1 (from
1 2 2
