1 Introduction
Blocking Protection for Pumps with SIMOCODE pro V
Article ID: 109478058, V2.0, 09/2020
7
© Siemens AG
2020 All rights reserved
Components
Quantity
Item number
Note
Digital module (DM
mono)
1
3UF7300-1AB00-0
optional
3
(If, for example, you wish
to connect indicator
lights for status feedback
to the
"Protection/Control"
function block)
SIMOCODE connecting
cable to basic unit
(Length: 0.025 m)
1
3UF7930-0AA00-0
Operator panel with
display
1
3UF210-1AA00-0
optional
4
SIMOCODE connecting
cable to operator panel
(Length 0.5 m)
1
3UF7932-0AA00-0
other
lengths
possible
SIRIUS USB PC cable
1
3UF7941-0AA00-0
For connecting the basic
unit to the source system
Alternatively, you can
connect the source
system to the
PROFINET interface of
the basic unit.
SIRIUS circuit breaker
1
3RV2311-0AC10
or another circuit
breaker, depending on
the required connection
values of the motor and
the user's preferences
for model version.
SIRIUS contactor
2
3RT2015-1BB42
or another contactor,
depending on the
required connection
values of the motor and
the user's preferences
for model version.
SIRIUS wiring module,
upper
1
3RA1913-3D
For reversing starter, for
contactor combinations
S00
SIRIUS wiring module,
lower
1
3RA1913-3E
Motor
1
−
depends on customer
requirement
IE FC RJ45 plug 180
10 units
6GK1901-1BB10-2AB0
optional,
Or another model of an
IE FC RJ45 plug
IE FC TP standard cable
Meter-
ware
6XV1840-2AH10
optional,
Or other Industrial
Ethernet bus cable
SIMOCODE ES V16
Standard Floating
License (DVD)
1
3ZS1322-6CC14-0YA5
SIMOCODE ES V16
Upgrade Floating
License (DVD)
3ZS1322-6CC14-0YE5
3
if the digital module is left out, it should be deleted from the device configuration in the project
engineering of the included example.
4
If the operator panel is left out, it should be deleted from the device configuration in the project
engineering of the included example.
