6.6 Configuring the DM-F PROFIsafe and integrating it into the fail-safe automation system using PROFIBUS/
PROFIsafe or PROFINET/PROFIsafe
50
SIMOCODE pro - Fail-Safe Digital Modules
Manual, 11/2017, NEB631679702000/RS-AA/002
Displaying the set PROFIsafe address and the DIP switch setting with
SIMOCODE ES (SIMOCODE ES 2007) or SIMOCODE ES (TIA-Portal)
You can display the PROFIsafe address set on the DM-F PROFIsafe online. To do this,
proceed as follows:
● Change to the online mode.
– SIMOCODE ES 2007: "Open switching device online"
– SIMOCODE ES (TIA Portal): "Go online"
● You can find the currently effective PROFIsafe address as follows:
DM-F PROFIsafe with
:
– SIMOCODE ES 2007: In the parameter tree under "Bus parameter"
– SIMOCODE ES (TIA-Portal): Under "Parameter → Fieldbus interface".
DM-F PROFIsafe with
:
– SIMOCODE ES 2007: In the parameter tree under "PROFINET parameter"
– SIMOCODE ES (TIA-Portal): Under "Parameter → Fieldbus interface".
You can find the DIP switch setting for the PROFIsafe address as follows:
● SIMOCODE ES 2007: Under "Target System → Actual configuration"
● SIMOCODE ES (TIA-Portal): Under "Commissioning → Actual configuration"
Configuring SIMOCODE pro V with DM-F PROFIsafe
For the configuration of SIMOCODE pro V with the DM-F PROFIsafe fail-safe digital module,
the following options are available to you:
By GSD / GSDML for use in S7 systems and "non-S7 systems" as fail-safe standard slave:
Note
Option package
Note that you still require the option package appropriate for the respective engineering
system. If you use, for example, the GSD
in STEP 7 classic, you require Distributed Safety
-Systems.
STEP 7 (TIA Portal)
– STEP 7 Safety (TIA Portal)
