10.6 Roller bearings, NDE













Figure 10-4 Roller bearings, NDE
Table 10-4 Spare parts for roller bearings, NDE
Part Description Part Description
4.21 Outer bearing cover (sealing cover) 4.61 Inner bearing cover
4.25 Seal 4.71 Insulating tube or insulating pipe
4.41 Deep-groove ball bearing 4.72 Insulating washer (screws)
4.50 Bearing housing 4.86 Spent grease chamber
4.52 Bearing enclosure bushing 4.94 Mounting parts
4.56 Insulating washer 6.00 Bearing shield
Spare parts
10.6 Roller bearings, NDE
SIMOTICS HV M 1RN76308PR900CG0-Z
114 Operating Instructions 07/2018
