Applications
The above-mentioned tightening torques apply for the following applications:
● Case A
Applies to electrical connections in which the permissible torque is normally limited by the
bolt materials and/or the current carrying capacity of the insulators, with the exception of
the busbar connections in case B.
● Case B
Applies to bolts screwed into components made from materials with lower property class
(e. g. aluminum) and to bolts with property class 8.8 according to ISO 898-1.
● Case C
Applies to bolts with property class 8.8, A4-70 or A4-80 according to ISO 898-1, however
only to bolts screwed into components made from materials with higher property class, e.g.
cast iron, steel or cast steel.
Note
Non-standard tightening torques
Different tightening torques for electrical connections and bolted connections for parts with
flat seals or insulating parts are specified in the relevant sections and drawings.
B.2 Maximum weights of the coupling
The motor is designed for flexible coupling. If the maximum weight of the coupling is exceeded,
check the feasibility.
Diameter of the shaft exten‐
sion
[mm]
Max. Weight of the coupling
halves for 2-pole motors
[kg]
Max. Weight of the coupling halves
for motors with 4-poles and higher
[kg]
50 10 10
55 10 20
60 10 20
65 10 20
70 20 30
75 20 30
80 20 40
85 30 50
90 30 50
95 30 60
100 40 70
105 40 80
110 50 90
115 50 100
120 60 110
125 70 130
130 70 140
Technical data and drawings
B.2 Maximum weights of the coupling
SIMOTICS HV M 1RN76308PR900CG0-Z
124 Operating Instructions 07/2018
