Preparing for use
4.5 Transport and storage
1LA5/6/7/9, 1LG4/6, 1MA6/7, 1MB..1/2/3/4/5 - SH 63 ... 355
Operating Instructions, 06/2018, A5E44455710A
35
Toppling over or slipping of the motor
The motor can slide or topple over if it is not correctly lifted or transported. This can result in
death, serious injury, or material damage.
• Use all the lifting eyes on the machine.
• When using the lifting eyes on the machine, do not attach any additional loads or
weight. The lifting eyes are only designed for the weight of the machine itself.
• Any eyes that are screwed in must be tightly fastened.
• Eyebolts must be screwed in right up to their supporting surface.
• Comply with the permissible eyebolt loads.
• When necessary, use suitably dimensioned lifting equipment, for example hoisting
straps (EN1492-1) and load restraints (EN12195-2).
● Never remain under or in the immediate vicinity of the machine when it is lifted. If the
lifting gear or load handling attachments were to fail, the machine could fall. This can
result in death, serious injury or material damage.
● In order to gain easy and safe access to the underside of the machine, place it in a
secure and raised position.
chines for transport, only lift them in a position that corresponds to their
The type of construction of the machine is stated on the rating plate.
If any transport locks are in place, remove them before commissioning. Store the transport
locks or disable them. Use the transport locks when transporting the motors again or
reactivate the transport locks.
The machines are packed in different ways depending on how they are transported and their
size. If not otherwise contractually agreed, the packaging corresponds to the packing
guidelines according to ISPM (International Standards for Phytosanitary Measures).
Comply with the images shown on the packaging. Their meaning is as follows:
Up Fragile
goods
Protect
against
Protect
against
Center of
gravity
Hand hooks
forbidden
Attach
here
